Rugged Fanless Computers

Rugged Fanless PCs Tested to MIL-STD-810, Rated Down to -40°C

Cincoze DS, DX, and DV series systems cool by conduction through an extruded-aluminum enclosure — no fan to fail — backed by MIL-STD-810H testing on the DS-1500, DX-1300, and DV-1100 (810G on the DS-1400), EN 50121-3-2 railway EMC (per EN 50155) on every model, and E-Mark vehicle certification on the DV-1100.

-40°C to 70°C at 35W TDP on the DS-1400 and DV-1100; -40°C to 60°C on the Core Ultra DS-1500 and DX-1300 — no fan
MIL-STD-810H shock and vibration tested (DS-1500, DX-1300, DV-1100); MIL-STD-810G on the DS-1400
9–48 VDC input with OVP, OCP, reverse-power protection
Up to 96 GB DDR5 ECC and 36 platform TOPS on the Core Ultra models
EN 50121-3-2 railway EMC (per EN 50155) on all featured models

Request a Quote

Tell us your application — a US-based engineer will reply within one business day.

Max Fanless Range, 35W TDP (with wide-temp peripherals; ambient airflow): -40°C to 70°C
Shock & Vibration Tested, All Featured Models: MIL-STD-810
Wide-Range Power Input: 9–48 VDC
Railway EMC (per EN 50155), All Featured Models: EN 50121-3-2
Industrial Computing Experience: 30+ yrs

Which Rugged Fanless PC Fits Your Job

All four run fanless from -40°C on 9–48 VDC and carry EN 50121-3-2 railway EMC (per EN 50155) — the differences are compute generation, expansion, and how hot they can go.

MIL-STD-810H

Cincoze DS-1500

Current-generation flagship — Intel Core Ultra 200S compute for machine control, data acquisition, and edge AI that has to survive shock, vibration, and deep cold.

Intel Core Ultra 200S (Arrow Lake-S), up to 24 cores / 5.6 GHz
-40°C to 60°C fanless at 35W TDP
Up to 96 GB DDR5-6400 ECC; up to 36 platform TOPS
1× 2.5GbE + 1× GbE, 2× RS-232/422/485, 8× USB, 2× SIM

View Specs

EN 45545-2

Cincoze DX-1300

Compact current-generation rugged system for transportation and heavy industry — the pick when serial I/O and railway compliance matter in tight spaces.

Intel Core Ultra 200S (Arrow Lake-S), up to 24 cores
-40°C to 60°C fanless at 35W TDP
MIL-STD-810H shock and vibration tested
2× 2.5GbE, 4× RS-232/422/485, RAID 0/1/5/10

View Specs

MIL-STD-810G

Cincoze DS-1400

Previous-generation expandable workhorse — a value pick for compute-heavy edge workloads that still need -40°C starts and MIL-STD-810G toughness.

BTL-S/14th/13th/12th Gen Intel Core up to Core i9
Up to 96 GB DDR5-5600, ECC or non-ECC
-40°C to 70°C fanless at 35W TDP
Hot-swap 2.5" bay, RAID 0/1/5/10, 2× SIM

View Specs

MIL-STD-810H

Cincoze DV-1100

Compact 2.52 kg system for vehicles and tight enclosures — E-Mark certified, with full rugged ratings and current-generation compute.

BTL-S/14th/13th/12th Gen Intel Core up to Core i9
-40°C to 70°C fanless at 35W TDP
1× 2.5GbE + 1× GbE, 2× RS-232/422/485
2.52 kg; DIN rail, VESA, or wall mount

View Specs

Where Rugged Fanless PCs Earn Their Keep

Plant-Floor Machine Control

Line control and data acquisition mounted to machinery — vibration-rated hardware with no fan to clog with airborne dust.

On-Vehicle Systems

9–48 VDC input, optional 12V/24V ignition sensing, and E-Mark certification on the DV-1100 for equipment fleets and specialty vehicles.

Rail and Wayside

EN 50121-3-2 railway EMC (per EN 50155) on all four featured models; the DS-1500 and DX-1300 add EN 45545-2 railway fire-protection compliance for onboard installs.

Outdoor and Remote Enclosures

Starts at -40°C in unheated cabinets — up to 70°C on the DS-1400 and DV-1100 — with a software-programmable watchdog timer on every featured model for unattended recovery.

Rugged in Numbers, Not Adjectives

Aluminum cooling-fin array on a fanless Cincoze industrial computer

Cooling With Nothing to Break

Every system on this page cools by conduction: the extruded-aluminum enclosure is the heatsink, so there is no fan bearing to wear out and no airflow pulling dust through the electronics.

DS-1400 and DV-1100: -40°C to 70°C with 35W-TDP processors (with extended-temperature peripherals; ambient with air flow)
DS-1500 and DX-1300: -40°C to 60°C at 35W TDP under the same conditions
Higher-TDP CPUs carry documented narrower ranges and add an external fan kit — 65W CPUs in the DS-1500 and DX-1300 are rated -40°C to 50°C with the kit installed

Cincoze DS-1502 expandable rugged embedded computer, front view

Shock and Vibration, Tested to Standard

The ratings come straight from the spec sheets:

DS-1500, DX-1300, and DV-1100: MIL-STD-810H tested for both shock and vibration
DS-1400: MIL-STD-810G tested, with a front-accessible hot-swap 2.5" bay and RAID 0/1/5/10
DS-1501 and DS-1502: a patented adjustable card retainer secures PCI/PCIe expansion cards in high-vibration installs

Configure any of them with M.2 or 2.5" solid-state storage to remove the last moving part from the system.

White commuter passenger train — the rail and vehicle environments these DC-input systems are built for

DC Power Built for Vehicles and Plants

All four systems accept 9–48 VDC and protect themselves with over-voltage, over-current, and reverse-power protection. For on-vehicle duty, an optional CFM module adds 12V/24V power ignition sensing — the DS-1500, DX-1300, and DS-1400 versions include delay time management for clean startup and shutdown with the vehicle.

Get Configuration Help

The Four Rugged Models Side by Side

The Four Rugged Models Side by Side
Spec	DS-1500	DX-1300	DS-1400	DV-1100
CPU options	Core Ultra 200S (Arrow Lake-S), up to 24 cores	Core Ultra 200S (Arrow Lake-S), up to 24 cores	BTL-S/14/13/12th Gen Core up to i9	BTL-S/14/13/12th Gen Core up to i9
Memory	2× DDR5-6400 ECC/non-ECC, up to 96 GB	2× DDR5-6400 ECC/non-ECC, up to 96 GB	2× DDR5-5600 ECC/non-ECC, up to 96 GB	1× DDR5-5600, up to 48 GB
Operating temp (35W TDP, wide-temp peripherals)	-40°C to 60°C	-40°C to 60°C	-40°C to 70°C	-40°C to 70°C
Shock / vibration	MIL-STD-810H	MIL-STD-810H	MIL-STD-810G	MIL-STD-810H
LAN	1× 2.5GbE + 1× GbE	2× 2.5GbE	2× GbE	1× 2.5GbE + 1× GbE
Serial ports	2× RS-232/422/485	4× RS-232/422/485	2× RS-232/422/485	2× RS-232/422/485
Key certifications	EN 50121-3-2 (per EN 50155), EN 45545-2, MIL-STD-810H, UL	EN 50121-3-2 (per EN 50155), EN 45545-2, MIL-STD-810H, UL	EN 50121-3-2 (per EN 50155), MIL-STD-810G, UL	EN 50121-3-2 (per EN 50155), MIL-STD-810H, E-Mark
Mounting	Wall	Wall / DIN rail / VESA / side	Wall	Wall / DIN rail / VESA
Weight	4.9 kg	3.59 kg	4.5 kg	2.52 kg

Rugged Fanless PC Questions, Answered

How can a fanless PC run reliably at 70°C?

By conduction cooling: the extruded-aluminum enclosure acts as the heatsink and moves processor heat to the outside surface, so there is no fan bearing to wear out and no airflow pulling dust into the electronics. The DS-1400 and DV-1100 are rated -40°C to 70°C with 35W-TDP processors and extended-temperature peripherals (ambient with air flow); the Core Ultra DS-1500 and DX-1300 are rated -40°C to 60°C on the same terms. Higher-wattage CPU options carry documented narrower ranges and pair with an external fan kit — for example, 65W CPUs in the DS-1500 are rated to 50°C with the kit installed.

What do the MIL-STD-810 shock and vibration ratings actually mean?

MIL-STD-810 is a US military test-method standard. Its shock methods apply short transient pulses — the kind of stress an impact or drop produces — while its vibration methods apply sustained random vibration profiles like those measured on vehicles and machinery, so the two ratings cover different failure modes. The DS-1500, DX-1300, and DV-1100 are tested to revision 810H for both shock and vibration, and the DS-1400 to revision 810G. Specifying M.2 or 2.5" solid-state storage instead of a rotating drive keeps the whole system inside those ratings.

What is the difference between MIL-STD-810 and EN 50155?

MIL-STD-810 is a US military environmental test-method standard; the DS-1500, DX-1300, and DV-1100 are shock and vibration tested to its 810H revision, and the DS-1400 to 810G. EN 50155 is the European standard for electronic equipment on railway rolling stock. The models on this page meet its EMC requirement — EN 50121-3-2 railway EMC — which is why we state the rating as EN 50121-3-2 (per EN 50155) rather than claiming the full clause set. The two standards are complementary rather than interchangeable.

Can these run from vehicle or battery power?

Yes. All four featured models accept 9–48 VDC with over-voltage, over-current, and reverse-power protection, and each supports optional 12V/24V power ignition sensing through a CFM expansion module so the computer starts and shuts down cleanly with the vehicle. The DV-1100 also carries E-Mark vehicle certification.

Which operating systems are supported?

All four list Windows 11 and Windows 10 support. On Linux, the DS-1500 and DX-1300 list Ubuntu 24.04, and the DS-1400 and DV-1100 list Ubuntu Desktop 22.04 LTS. Tell us your target OS in the quote form and we'll configure the system to match.

Can you configure a system for my application, or support OEM volume?

Yes — tell us your requirements and we'll configure memory, storage, OS, and expansion to match. We also support OEM and volume programs; mention quantities in your request and a US-based engineer will reply within one business day.

Spec a Rugged Fanless PC for Your Environment

Send your temperature, power, and mounting requirements — a US-based engineer will reply within one business day.

Request a Quote Call 603-895-9000
