DIN Rail Industrial Computers
DIN Rail PCs for Control Cabinets — Slim Fanless Boxes to 14th Gen Core
Mount on the rail, wire to 9–48 VDC, and close the panel. Four cabinet-ready models, from a 52.3 mm-thick gateway box to the MD-3000 with socketed 14/13/12th Gen Intel Core processors.
- DIN-rail mounting on all four featured models
- 9–48 VDC wide-range DC input across the lineup
- -40°C to 70°C fanless on the DC-1200-N42
- Up to 96 GB DDR5 and 5× GbE LAN on the MD-3000
- 50 Grms shock on the DA-1000, DC-1200, DE-1000
Request a Quote
Tell us your application — a US-based engineer will reply within one business day.
Which DIN Rail PC Fits Your Cabinet
Four DIN-mountable models spanning entry gateways to desktop-class control — every spec below comes straight from the datasheet.
Cincoze MD-3000
DIN-rail-native flagship for cabinet-based machine control, vision, and data-heavy edge workloads.
- 14/13/12th Gen Intel Core (LGA1700)
- Up to 96 GB DDR5, 2× M.2 NVMe with RAID
- 5× GbE LAN, 4× USB 3.2, 2× DisplayPort
- -40°C to 65°C (35 W TDP), 9–48 VDC
Cincoze DA-1000
Palm-size entry box for protocol gateways and light control where rail space is tightest.
- Intel Atom E3826, 7 W TDP
- -25°C to 70°C fanless operation
- 2× GbE, 2× RS-232/422/485, 4× USB
- 150 × 105 × 52.3 mm, 0.86 kg
E-Mark
Cincoze DC-1200-N42
Compact mid-tier with modular CMI/CFM slots for data acquisition and line control that may grow.
- Intel Pentium N4200 quad-core
- -40°C to 70°C fanless, 9–48 VDC
- 2× GbE, 4× USB 3.2 Gen 1, triple display
- 2× CMI + 2× CFM expansion slots
EN 50155
Cincoze DE-1000
Serial-heavy workhorse for PLC and SCADA gateways that talk to racks of legacy equipment.
- Intel Atom E3845 quad-core, 10 W
- 6× RS-232/422/485, 2× GbE
- 2× 2.5" bays + mSATA + CFast
- Built-in ignition sensing (12V/24V)
Side by Side: Four DIN-Mountable Models
| DA-1000 | DC-1200-N42 | DE-1000 | MD-3000 | |
|---|---|---|---|---|
| CPU | Atom E3826, 2 cores | Pentium N4200, 4 cores | Atom E3845, 4 cores | 14/13/12th Gen Core (LGA1700) |
| Max memory | 8 GB DDR3L | 8 GB DDR3L | 8 GB DDR3L (2 slots) | 96 GB DDR5 (ECC capable) |
| LAN | 2× GbE | 2× GbE | 2× GbE | 5× GbE |
| Serial ports | 2× RS-232/422/485 | 2× RS-232/422/485 | 6× RS-232/422/485 | 1× RS-232/422/485 |
| Storage | 2.5" SATA + mSATA | 2.5" SATA + mSATA | 2× 2.5" + mSATA + CFast | 2× M.2 NVMe, RAID |
| Operating temp | -25°C to 70°C | -40°C to 70°C | -25°C to 70°C | -40°C to 65°C (35 W TDP) |
| Cooling | Fanless | Fanless | Fanless | Smart fan |
| Expansion | 2× Mini-PCIe, 1× CMI | 2× Mini-PCIe, 2× CMI + 2× CFM | 2× Mini-PCIe | PCIe x16 SED expansion deck |
| Mounting | DIN rail, VESA, wall | DIN rail, VESA, wall | DIN rail, VESA, wall | DIN rail, wall |
Engineered for Panel Builders
Built for the Control Cabinet
Every model on this page lists DIN rail among its mounting options, so the computer clips into the same enclosure real estate as your relays and PLC — no shelf, no tray. The DA-1000 occupies a 150 × 105 mm footprint at 52.3 mm thick and 0.86 kg.
Power comes from the cabinet itself: all four models accept 9–48 VDC, so a standard 24 VDC control-power supply works as-is. The DA-1100-N42, DC-1200-N42, and MD-3000 add over-voltage, over-current, and reverse-power protection on the DC input.
Fanless Cooling Inside a Sealed Panel
Cabinets trap heat, and fans pull in the dust a sealed panel is supposed to keep out. The DA, DC, and DE units here are fanless: an extruded-aluminum enclosure conducts CPU heat to external fins — no moving parts, no filters to service.
Rated results: -40°C to 70°C on the DC-1200-N42, and -25°C to 70°C on the DA-1000 and DE-1000 (with extended-temperature or industrial-grade peripherals, ambient with air flow), plus operation at up to 95% non-condensing humidity.
Room to Grow Without Leaving the Rail
I/O lists change after commissioning. The DC-1200-N42 carries 2× CMI and 2× CFM module slots plus two Mini-PCIe sockets; the DA-1000 carries two Mini-PCIe sockets plus a CMI slot. The optional CFM module adds power ignition sensing (12V/24V selectable) for vehicle-fed or mobile panels.
The MD-3000 goes further: a PCIe x16 interface for an optional Scalable Expansion Deck (SED), dual M.2 NVMe slots with RAID, and up to 96 GB of DDR5 — desktop-class headroom in a DIN-rail form factor.
DIN Rail PC Questions
Will these PCs mount on the standard DIN rail in my enclosure?
How much thermal clearance does a fanless PC need inside a cabinet?
Can I power these from a 24 VDC control-power supply?
What if I need more performance than a Pentium or Atom class box?
Can ADEK configure memory, storage, and OS before delivery?
Do you support OEM and volume programs?
Put Your Next Controller on the Rail
Send your I/O list, power budget, and cabinet layout — a US-based engineer will reply within one business day.
